      BWP352 LED57/NW 40W 220-240V DM2 G2
      BWP352 LED57/NW 40W 220-240V DM2 G2
      FlowBase G2

      BWP352 LED57/NW 40W 220-240V DM2 G2

      Downloads

      Spec Sheet
      Size:432.2 kB

      See all downloads

    Specifications Show all

    Operating and Electrical
    Input Frequency
    50 or 60 Hz
    Power Factor (Fraction)
    0.9
    Input Voltage
    220 to 240 V
    Cable
    Cable 0.5 m without plug
    Connection
    Flying leads/wires
    Power Consumption
    40 W
    Line Frequency
    50 or 60 Hz
    Approval and Application
    Protection class IEC
    Safety class I
    CE mark
    CE mark
    Ingress protection code
    IP66  [Dust penetration-protected, jet-proof]
    Mech. impact protection code
    IK08  [6 J]
    Product Data
    Numerator - Quantity Per Pack
    1
    EAN/UPC - Case
    6922341979248
    EAN/UPC - Product
    6922341979248
    Material number (12NC)
    911401629807
    Full product name
    BWP352 LED57/NW 40W 220-240V DM2 G2
    Full product code
    692234197924899
    Numerator - Packs per outer box
    2
    Order product name
    BWP352 LED57/NW 40W 220-240V DM2 G2
    Order code
    911401629807
    Controls and Dimming
    Control interface
    Analog
    Dimmable
    Yes
    General Information
    Driver included
    Yes
    Mechanical and Housing
    Overall width
    123 mm
    Optical cover/lens material
    Polycarbonate
    Housing Color
    Dark gray
    Dimensions (Height x Width x Depth)
    91 x 123 x 374 mm
    Housing Material
    Aluminum die cast
    Overall length
    374 mm
    Overall height
    91 mm
    Initial Performance (IEC Compliant)
    Power consumption tolerance
    +/-10%
    Luminous flux tolerance
    +/-10%
    Temperature
    Ambient temperature range
    -40 to +55 °C
    Light Technical
    Correlated Color Temperature (Nom)
    4000 K
    Luminous Efficacy (rated) (Nom)
    140 lm/W
    Color rendering index (CRI)
    >70
    Light source color
    740 neutral white
    Optical cover/lens type
    Polycarbonate micro lens optic
    Luminous Flux
    5,700 lumen
    Installation Diagrams
    FlowBase G2
    FlowBase G2
