    • UrbanSpark Gen 3 all in one solar post top lantern

      ZJS602 60Ah 12.8V Battery IN
      ZJS602 60Ah 12.8V Battery IN
      UrbanSpark Gen 3

      ZJS602 60Ah 12.8V Battery IN

    Specifications Show all

    Operating and Electrical
    Battery ampere hour
    60 Ah
    Battery voltage
    12.8 V
    Battery type
    Lithium Ferro Phosphate
    Battery charging & discharging cycles
    2000
    Approval and Application
    Ingress protection code
    IP68  [Dust penetration-protected, pressure watertight]
    Mech. impact protection code
    IK10  [20 J vandal-resistant]
    Product Data
    Numerator - Quantity Per Pack
    1
    Full product name
    ZJS602 60Ah 12.8V Battery IN
    Numerator - Packs per outer box
    2
    Order product name
    ZJS602 60Ah 12.8V Battery IN
    Material number (12NC)
    919415811282
    Order code
    919415811282
    Mechanical and Housing
    Overall width
    146 mm
    Housing Color
    Black
    Material
    Acrylonitrile-butadiene-styrene
    Dimensions (Height x Width x Depth)
    470 x 146 x 120 mm
    Overall length
    120 mm
    Overall height
    470 mm
    Application Conditions
    Solar dimming profile
    -
    Ambient temperature range for charging
    0 °C to +45 °C °C
    Ambient temperature range for discharging (when light is on)
    -20 °C to +60 °C °C
    Temperature
    Ambient temperature range
    0 to +35 °C
    Installation Diagrams
    Dimension Drawing (without table) - ZJS602 60Ah 12.8V Battery IN
    Dimension Drawing (without table) - ZJS602 60Ah 12.8V Battery IN
