| Charge controller type | MPPT
|
| Battery type | Multiple
|
| Charge controller wattage | 180
W
|
| CE mark | CE mark
|
| Warranty period | 3 years
|
| EU RoHS compliant | Yes
|
| Ingress protection code | IP67
[Dust penetration-protected, watertight] |
| Numerator - Quantity Per Pack | 1
|
| Full product code | 911401822902
|
| Full product name | ZJS403 CCC 600 12V/24V RS
|
| Numerator - Packs per outer box | 8
|
| Order product name | ZJS403 CCC 600 12V/24V RS
|
| Material number (12NC) | 911401822902
|
| Order code | 911401822902
|
| Control interface | RS-485
|
| Dimmable | Wireless Dim
|
| Driver included | Yes
|
| Overall width | 87.8
mm
|
| Dimensions (Height x Width x Depth) | 43 x 88 x 200 mm
|
| Overall length | 200
mm
|
| Overall height | 42.5
mm
|
| Grid connection type | Off grid
|
| Ambient temperature range | -20 to +60 °C
|
| Luminous Efficacy (rated) (Nom) | 160
lm/W
|
