      BRP331 LED48 CW R5N PC PSU S1
      BRP331 LED48 CW R5N PC PSU S1
      CityStar

      BRP331 LED48 CW R5N PC PSU S1

      Order code: 919515815528

      Downloads

      Spec Sheet
      Size:1.1 MB

      See all downloads

    Specifications Show all

    General information
    Beam angle of light source
    120 °
    Light source color
    757 cool white
    Driver included
    Yes
    Optical cover/lens type
    Polycarbonate
    Luminaire light beam spread
    130° x 88°
    Control interface
    -
    Protection class IEC
    Safety class I (I)
    Flammability mark
    F  [ For mounting on normally flammable surfaces]
    Warranty period
    3 years
    Material
    Aluminum
    Optic type outdoor
    Distribution Symmetric Wide
    Light source engine type
    LED
    Operating and electrical
    Input Voltage
    140-270 V
    Input Frequency
    50 Hz
    Power Factor (Min)
    0.95
    Controls and dimming
    Dimmable
    No
    Mechanical and housing
    Housing Material
    Aluminium pressure die cast
    Optic material
    Polycarbonate
    Optical cover/lens material
    Polycarbonate
    Mounting device
    34/42  [ Spigot for diameter 34-42 mm]
    Color
    Aluminum and gray
    Approval and application
    Ingress protection code
    IP66  [ Dust penetration-protected, jet-proof]
    Mech. impact protection code
    IK07  [ 2 J reinforced]
    Surge Protection (Common/Differential)
    4/4 kV
    Initial performance (IEC compliant)
    Initial luminous flux (system flux)
    4800 lm
    Initial LED luminaire efficacy
    120 lm/W
    Init. Corr. Color Temperature
    5700 K
    Init. Color Rendering Index
    >70
    Initial input power
    40 W
    Power consumption tolerance
    +/-10%
    Over time performance (IEC compliant)
    Median useful life L70B50
    50000 h
    Application conditions
    Ambient temperature range
    -10 to +50 °C
    Product data
    Order product name
    BRP331 LED48 CW R5N PC PSU S1
    Order code
    919515815528
    Numerator - Quantity Per Pack
    1
    Numerator - Packs per outer box
    10
    Material Nr. (12NC)
    919515815528
    Net Weight (Piece)
    0.850 kg
    Installation Diagrams
    CityStar 30,35,40&45W
    CityStar 30,35,40&45W
    Downloads
    Leaflets
    Visuals
    Software Plugins
    • IES BRP331 LED48 CW R5N PC PSU S1 919515815528.ies IES 30.9 kB
