      ST033T LED25/840 30W 220-240V I MB WH GM
      ST033T LED25/840 30W 220-240V I MB WH GM
      Essential Smartbright Projector Gen 2

      ST033T LED25/840 30W 220-240V I MB WH GM

    Specifications Show all

    Operating and Electrical
    Input Frequency
    50 or 60 Hz
    Number of products on MCB of 16 A type B
    70
    Power Factor (Fraction)
    0.9
    Input Voltage
    220 to 240 V
    Inrush current
    18 A
    Power Consumption
    30 W
    Line Frequency
    50 or 60 Hz
    Approval and Application
    Protection class IEC
    Safety class I
    CE mark
    -
    Ingress protection code
    IP20  [Finger-protected]
    Mech. impact protection code
    IK03  [0.3 J]
    Flammability mark
    -
    Product Data
    Numerator - Quantity Per Pack
    1
    EAN/UPC - Case
    8719514544574
    Material number (12NC)
    911401890482
    Full product code
    871951454429199
    Full product name
    ST033T LED25/840 30W 220-240V I MB WH GM
    Order product name
    ST033T LED25/840 30W 220-240V I MB WH GM
    Numerator - Packs per outer box
    24
    Order code
    911401890482
    Controls and Dimming
    Control interface
    -
    Dimmable
    No
    General Information
    Light source engine type
    LED
    Mechanical and Housing
    Overall width
    76 mm
    Optical cover/lens material
    Polycarbonate
    Housing Color
    White
    Housing Material
    Aluminum
    Dimensions (Height x Width x Depth)
    235 x 76 x 93 mm
    Overall length
    93 mm
    Overall diameter
    76 mm
    Overall height
    235 mm
    Optical cover/lens finish
    Textured
    Initial Performance (IEC Compliant)
    Initial chromaticity
    (0.3811, 0.3772) SDCM <5
    Power consumption tolerance
    +/-10%
    Luminous flux tolerance
    +/-10%
    Temperature
    Ambient temperature range
    -20 to +45 °C
    Light Technical
    Correlated Color Temperature (Nom)
    4000 K
    Luminous Efficacy (rated) (Nom)
    85 lm/W
    Color rendering index (CRI)
    >80
    Optical cover/lens type
    Fashion proof optic beam angle 24°
    Light source color
    840 neutral white
    Luminous Flux
    2,500 lumen
    Installation Diagrams
    Dimension Drawing (without table) - ST033T LED25/840 30W 220-240V I MB WH GM
    Dimension Drawing (without table) - ST033T LED25/840 30W 220-240V I MB WH GM
