BN308C LED60S-4000  L120 PIR WH

Specifications Show all

General information

Beam angle of light source	120 °
Light source color	840 neutral white
Driver included	Yes
Optic type	120  [ Beam angle 120°]
Optical cover/lens type	Polycarbonate
Luminaire light beam spread	120°
Control interface	-
Protection class IEC	Safety class I (I)
Flammability mark	F  [ For mounting on normally flammable surfaces]
Warranty period	2 years
Material	Steel
Light source engine type	LED

Operating and electrical

Input Voltage	140-270 V
Input Frequency	50 Hz
Power Factor (Min)	0.95

Controls and dimming

Dimmable

No

Mechanical and housing

Housing Material	Steel
Optic material	Polycarbonate
Optical cover/lens material	Polycarbonate
Mounting device	Surface & Suspended (Asymmetric/ Symmetric)
Color	White

Approval and application

Ingress protection code	IP20  [ Finger-protected]
Mech. impact protection code	IK02  [ 0.2 J standard]
Surge Protection (Common/Differential)	Surge protection level until 4 kV

Initial performance (IEC compliant)

Initial luminous flux (system flux)	6000 lm
Initial LED luminaire efficacy	120 lm/W
Init. Corr. Color Temperature	4000 K
Init. Color Rendering Index	>80
Initial chromaticity	<5
Initial input power	47 W
Power consumption tolerance	+/-10%

Over time performance (IEC compliant)

Median useful life L70B50

50000 h

Application conditions

Ambient temperature range

0 to +45 °C

Product data

Order product name	BN308C LED60S-4000  L120 PIR WH
Order code	919515812685
Numerator - Quantity Per Pack	1
Numerator - Packs per outer box	6
Material Nr. (12NC)	919515812685
Net Weight (Piece)	1.500 kg
