BBP403 LED50/WW 2W 24V L300

Specifications Show all

General information

Light source color	830 warm white
Light source replaceable	No
Driver included	Yes
Optical cover/lens type	G  [ Glass]
Control interface	-
Connection	Screw connection block 2-pole
Cable	Cable 0.3 m with connector 2-pole
Protection class IEC	Safety class III (III)
Flammability mark	NO  [ -]
CE mark	-
Light source engine type	LED
Serviceability class	Class C, luminaire without serviceable parts, not serviceable

Light technical

Standard tilt angle posttop

-

Operating and electrical

Input Voltage	24 DC V
Input Frequency	- Hz
Power Factor (Min)	-
Power Factor (Nom)	-

Controls and dimming

Dimmable

No

Mechanical and housing

Housing Material	Aluminum
Optic material	Glass
Optical cover/lens material	Polycarbonate
Mounting device	RMR  [ Recessed mounting box round]
Optical cover/lens finish	Frosted
Overall length	300 mm
Overall width	48 mm
Overall height	108 mm
Color	Aluminum and gray
Dimensions (Height x Width x Depth)	108 x 48 x 300 mm

Approval and application

Ingress protection code	IP67  [ Dust penetration-protected, watertight]
Mech. impact protection code	IK10  [ 20 J vandal-resistant]

Initial performance (IEC compliant)

Initial luminous flux (system flux)	50 lm
Luminous flux tolerance	+/-10%
Initial LED luminaire efficacy	30 lm/W
Init. Corr. Color Temperature	3000 K
Init. Color Rendering Index	>80
Initial input power	1.6 W
Power consumption tolerance	+/-10%

Application conditions

Ambient temperature range

-40 to +50 °C

Product data

Full product code	871951494830399
Order product name	BBP403 LED50/WW 2W 24V L300
EAN/UPC - Product	8719514948303
Order code	911401755422
Numerator - Quantity Per Pack	1
Numerator - Packs per outer box	4
Material Nr. (12NC)	911401755422
Net Weight (Piece)	1.000 kg
